AGV Transfer Cart for Industry (1-300Ton)
Industrial Automated Guided Vehicle (AGV) Motorized Transfer Cart: 1-300 Ton for Intelligent Material Handling
Our Automated Guided Vehicle (AGV) electric transfer vehicle aims to change the way industrial logistics is transported through automation technology, providing intelligent and efficient material handling solutions for goods ranging from 1 to 300 tons. These advanced AGVs combine electric precision with automatic navigation, simplifying material transportation between factories, warehouses, and production facilities, reducing the involvement of manual operations, and improving work efficiency in factory workshops.
Product Introduction
Dual support of automation and remote control
This is a 25 ton AGV transport vehicle with dual operation modes of automation and remote control:
It can automatically move forward and turn according to the preset path, and can also flexibly control the front and rear, left and right steering with a remote control, adapting to the precise and efficient material handling needs in industrial scenes, and assisting in intelligent operation processes.
Products Parameters
The core of this car is the automatic navigation system, which uses cutting-edge technologies such as laser navigation, visual sensors, or tape navigation to draw a route map, avoid obstacles, and walk through the factory workshop according to the set route without manual control. This enables transport vehicles to operate autonomously, following pre programmed paths or adapting to real-time environmental changes to ensure accurate and timely delivery between production stations, storage areas, and processing lines.
| Model | 2t | 20t | 50t | 100t | 150t | |
| Rated Load(t) | 2 | 20 | 50 | 100 | 150 | |
| Table Size(mm) | Length(L) | 2000 | 4000 | 5500 | 6500 | 10000 |
| Width(W) | 1500 | 2200 | 2500 | 2800 | 3000 | |
| Heigth(H) | 450 | 550 | 650 | 900 | 1200 | |
| Wheel Base(mm) | 1200 | 2800 | 4200 | 4900 | 7000 | |
| Rail Inner Gauge(mm) | 1200 | 1435 | 1435 | 2000 | 2000 | |
| Wheel Diameter(mm) | 270 | 350 | 500 | 600 | 600 | |
| Wheel Quantity | 4 | 4 | 4 | 4 | 8 | |
| Ground Clearance(mm) | 50 | 50 | 50 | 75 | 75 | |
| Running Speed(min) | 0-25 | 0-20 | 0-20 | 0-20 | 0-18 | |
| Motor Power(kw) | 1 | 2.2 | 5 | 10 | 15 | |
| Running time When Full Load | 4.32 | 4 | 3.3 | 3.2 | 2.9 | |
| Running Distance for Once Charge(KM) | 6.5 | 4.8 | 4 | 3.8 | 3.2 | |
| Reference Weight(t) | 2.8 | 5.9 | 8 | 14.6 | 26.8 | |
| Recommended Rail Model | P15 | P24 | P43 | QU100 | QU100 | |
The advantages of AGV transport vehicles can be summarized as follows:
Automation: Unmanned operations, intelligent docking system scheduling, reducing manual labor consumption and improving efficiency.
Accurate and stable: high-precision positioning (± 5mm level), smooth operation, and reduced cargo loss.
Flexible and strong: No need to lay tracks, easy to change paths, adaptable to multiple scenarios and diverse transportation needs.
Safer: Multi sensor obstacle avoidance and emergency stop protection to avoid the risk of human error.
Traceability: Collecting operational and material data to assist in process optimization and quality traceability.
Main structural diagram of industrial Agv robot automatic guided vehicle
-
Magnetic Stripe
Can provide stable navigation paths for AGVs, adapt to complex industrial layouts, and have flexible installation and adjustment. -
Lithium Battery
It has the advantages of long lifespan, low energy consumption, low noise, compact size that does not take up space, and environmentally friendly electricity without pollution. -
Polyurethane Wheel
The interior of the wheel body is flexible and has good cushioning properties, while the outer layer is made of cast steel to ensure strong wear resistance. It can effectively absorb shock during driving, protect the ground from scratches, and balance the smooth operation of equipment and site protection. -
Wireless Network
Based on the application of wireless LAN technology in industrial control, a stable data transmission channel is constructed, which can adapt to the complex electromagnetic environment of factories, ensure real-time interaction of instructions, status and other data between AGV and control systems, and assist in intelligent scheduling. -
Scanning Radar (SCANNING RADAR, Above)
Integrate multiple functions, can be operated as a computer, supports touch interaction, and adapts to the diverse needs of intelligent workshops. -
Scanning Radar (below)
Compact and lightweight, easy to install and deploy. Equipped with self checking function, it can monitor the device status in real time
Perfect AGV intelligent transfer vehicle: completely changing your material handling!
Perfect's AGV intelligent transfer vehicle aims to simplify the process!
It is equipped with a magnetic induction device that can intelligently navigate and accurately handle loads of up to 2.5 tons. It is specifically designed for seamless automation, reducing manual labor, improving efficiency, and ensuring stable and safe operation.
'Perfect makes operation easier' is not just our slogan for redefining industrial workflows with our carts. Whether in the factory or warehouse, Perfect can transform your material transportation into a smooth and intelligent process.
Choose the perfect AGV that combines innovation with reliability and worry free handling!
