Steel Tube Transfer Carriage
Steel Tube Transfer Carriage
Product Title
BXC Series Battery-Powered Rail Transfer Cart - Heavy-Duty Electric Trolley for Long-Distance Material Handling (DC Motor, Remote Control, CE Certified)
Ideal for Steel Coils, Molds, and Heavy Loads in Foundries, Warehouses & Industrial Plants
Steel Coil & Mold Handling Rail Cart - Battery Operated with VFD Speed Control & Hydraulic Lift (BXC Series)
Perfect for Metallurgical Plants, Foundries, and Logistics Centers
Curved Track Ready! BXC Battery Rail Cart with V-Shape Rack & Hydraulic Platform - For Complex Workshop Layouts
Introduction
Tired of being tied down by cables? Meet the BXC Series - a battery-powered rail transfer cart built for factories that need to move heavy loads without limits. Whether you're hauling steel coils, molds, or machinery parts, this 1–150 ton workhorse runs on standard rails - no cables, no reels, no boundaries.
Go Anywhere - No Cables, No Limits
Unlike cable reels that tie you to short distances, the BXC Series runs as far as your rails go. Charge it up, and it keeps moving - perfect for long-distance material handling in sprawling factories or warehouses.
Fits Right In - Standard Rails, Zero Modifications
No need to install special insulation or rectification stations. The BXC works on P18/P24/P38/P43 - the same on railses you probably already have. Even handles turnouts and crossings, so you can adapt it to your existing layout.
Handles Curves, Corners & Complex Layouts
Most carts only go straight. Ours? Smooth on L-shapes, S-curves, even tight arcs. Whether you're moving materials across bays or between buildings, the BXC navigates complex workshop layouts like a pro.
Powerful DC Motor - Built for Heavy Loads
Featuring a high-torque DC traction motor, the BXC starts smoothly, runs quietly, and stays stable under heavy loads. SEW, Siemens, or ABB motors available on request - because your factory deserves the best.
Wireless Remote - Safe, Simple, Reliable
Control from up to 30 meters away with our 36V safe-voltage remote. Intuitive buttons for forward/backward, speed, and emergency stop. Imported Swedish components ensure long-range, reliable performance.
Heavyweight Champion - 1 to 150 Tons (Customizable)
From 1-ton molds to 150-ton machinery, the BXC handles it all. Custom engineering available for even heavier loads. Box girder frame, 150% safety factor - built to last, not just to carry.
Low Maintenance - Spend Less Time Fixing, More Time Moving
Simple mechanical structure, fewer parts, less wear. Choose lead-acid or lithium iron phosphate batteries - lithium means longer life, lighter weight, fewer charges. ZG55 crane steel wheels? They're built to outlast your production schedule.
Clean & Green - Zero Emissions, Quiet Operation
No exhaust, no oil leaks, no noise pollution. Perfect for food plants, pharma clean rooms, electronics manufacturing - anywhere air quality matters.
How is BXC different from BJT (cable reel cart)?
A: Both run on tracks, but the power source is different.
BXC = battery-powered (lithium or lead-acid). No cables, no 24-hour power needed.
BJT = AC power via cable reels. Can run continuously, but you're tied to the cable length.
Can our steel coil truck move along the track?
A: Absolutely. It's designed for L-shapes, S-curves, arcs - even tight turnouts. Ideal for factories with complex layouts or limited space.
How far can the BXC go on a single charge?
A: As far as your rails take you - no distance limit. But battery life depends on load and speed. Typically 4–8 hours per charge. Heavy loads or high speeds? Expect less. Light use? Go longer.
Do I need special insulated rails?
A: Nope. Standard P18/P24/P38/P43 rails work fine. No insulation needed. Saves you money and hassle during installation.
Is the BXC safe for explosive environments?
A: Yes - we offer explosion-proof and high-temperature protection. Certified for use in chemical plants, oil refineries, grain facilities. Just let us know your hazard zone classification when requesting a quote.
What voltages are available?
A: Standard battery voltages: 24V, 36V, 48V, 72V DC.
Charger input: AC 220V / 380V / 400V / 415V, 50Hz or 60Hz - customize to your local power standard.
Case Study: BXC Series Battery Rail Cart in Israeli Steel Plant (EAF Shop)
Client: A leading Electric Arc Furnace (EAF) steel plant in Ashdod, Israel
Challenge: The client faced significant logistical bottlenecks in transporting heavy steel coils and EAF slag pots across their 800-meter production floor. Traditional forklifts were inefficient, unsafe around high-heat zones, and could not operate on fixed rail lines required for precision movement.
Solution: We delivered two BXC-100T Battery Powered Rail Transfer Carts customized with:
High-Temperature Resistant Deck: Lined with fireproof insulation to withstand radiant heat from nearby furnaces.
VFD Speed Control: Enabled smooth acceleration/deceleration to protect sensitive metallurgical equipment during transit.
Extended Range Lithium Battery: 72V/500Ah system providing 10+ hours of continuous operation per charge.
Results:
Increased daily material throughput by 40% by eliminating waiting times for charging or refueling.
Reduced safety incidents related to manual handling of hot materials to zero over 12 months.
Eliminated dependency on overhead catenary wires, allowing flexible routing between bays.
