Turntable Electric Flat Carriage

Turntable Electric Flat Carriage

When the flat car walks to the cross track, because the upper part of the turntable electric flat carriage is covered with tracks, the flat car can directly move to the turntable, and the reducer is driven by the motor to rotate the turntable (usually set in advance in rotation angle) and dock with another track to achieve change rail function.
Send Inquiry
Product Details ofTurntable Electric Flat Carriage

Turntable Electric Flat Carriage



When the flat car walks to the cross track, because the upper part of the turntable electric flat carriage is covered with tracks, the flat car can directly move to the turntable, and the reducer is driven by the motor to rotate the turntable (usually set in advance in rotation angle) and dock with another track to achieve change rail function.

The turntable electric flat carriage can rotate in multiple directions, and the user can rotate according to the actual working conditions. It is necessary to lay tracks on the surface of the turntable, so that the flat car can go to the required place to turn and change tracks. By rotating the turntable and then driving the flat car to change the track, this process can save space and time.

Product Description

_03

The Turntable Rail Transfer Cart is specifically engineered for cross-track transport of rail-bound vehicles. In factory settings, it enables 90° rotation to facilitate rapid adjustment of railway vehicles and efficient vehicle scheduling-streamlining material flow and optimizing the use of track infrastructure.

Working Principle

A core design feature resides in the direct integration of guide rails onto the turntable. Upon a rail-mounted transport vehicle driving onto the turntable platform, the turntable may be rotated either automatically or manually. Rotation proceeds until the turntable-integrated rails are precisely aligned with the target track; once accurate alignment is confirmed, the transport vehicle may proceed smoothly onto the perpendicular rail to complete the transfer operation.

Application & Performance Highlights

Versatile Track Compatibility: The Turntable Rail Transfer Cart is suitable for diverse track layouts, including circular rails, vertical rails, and cross rails-adapting to complex factory configurations and varied transport needs.

Superior Operational Performance: It operates with smooth, low-vibration movement and boasts exceptional rail alignment accuracy, ensuring stable, collision-free transfer of vehicles even when handling heavy loads.

Automation Capability: For enhanced efficiency and reduced manual intervention, a PLC (Programmable Logic Controller) can be integrated into the system. This enables fully automated electrical operation, aligning with smart factory workflows and minimizing operational errors.



_04_02

Self Propelled Electric Remote Control Rail Flat Cart Turntable
