Trolley Transport
Application：Steel Industry, Factory, Warehouse, Port
Brand：Perfect
Load Capacity：1-300 Ton
Special Function：Anti-Explosion, Heat-Resistant, Lifting
Control Mode：Pendant/Remote/PLC Control
Power Mode：Battery/cable powered/rail powered....
Color:Customzied
Trademark:PERFECT
Transport Package:The Whole Cart Will Be Packed by Tarp.
Specification:Customized
Send Inquiry
Product Details ofTrolley Transport
Trackless electric flat car is a kind of wheeled handling equipment that can be manually controlled and steered at will. It can help solve the problems of limited space, equipment that cannot be deployed, the need for transition operations, and difficult equipment disassembly and handling.
Perfect's trackless electric flat car is a wheeled handling equipment that can be steered at will by manual control. The power supply method is battery power supply, and the driving wheel and bearing wheel can be made of high-strength polyurethane rubber solid tires or pneumatic tires. Restricted by space and ground, the walking direction and route can be changed at any time, which is very suitable for occasions where the running route is not fixed.
| Model | BWP-2T | BWP-10T | BWP-20T | BWP-30T | BWP-50T | BWP-63T | BWP-150T | |
| Rated load (T) | 2 | 10 | 20 | 30 | 50 | 63 | 150 | |
| Table size | length(L) | 2000 | 3600 | 4000 | 4500 | 5500 | 5600 | 10000 |
| Width(W) | 1500 | 2000 | 2200 | 2200 | 2500 | 2500 | 3000 | |
| Height(H) | 450 | 500 | 550 | 600 | 650 | 700 | 1200 | |
| Wheel Base (mm) | 1200 | 2600 | 2800 | 3200 | 4200 | 4300 | 7000 | |
| Wheel Diameter(mm) | Φ270 | Φ300 | Φ350 | Φ400 | Φ500 | Φ600 | Φ600 | |
| Ground Clearance (mm) | 50 | 50 | 50 | 50 | 50 | 75 | 75 | |
| Motor Power (Kw) | 1 | 1.6 | 2.2 | 3.5 | 5 | 6.3 | 15 | |
| Battery Capacity(Ah) | 180 | 160 | 180 | 250 | 330 | 400 | 600 | |
| Battery Voltage(V) | 24 | 48 | 48 | 48 | 48 | 48 | 72 | |
| Running Time When Full Load | 4.32 | 4.8 | 4 | 3.5 | 3.3 | 3 | 2.9 | |
| Running Distance for one Charge(Km) | 6.5 | 7.2 | 4.8 | 4.2 | 4 | 3.6 | 3.2 | |
| Max Wheel Load (KN) | 14.4 | 42.6 | 77.7 | 110.4 | 174 | 221.4 | 265.2 | |
Henan Perfect Handling Equipment Co., Ltd. specializes in the production of more than 80 products such as electric flat cars, track flat cars, trackless electric flat cars, ladle cars, etc. It is a manufacturer of electric flat cars as its main products. According to the needs of car users, our company can design and customize electric flat car spare parts of various specifications and models for our customers to update, replace or transform electric flat cars, reducing the investment cost of users.
