Introduction

The rail mounted transfer cart is a flatbed truck that runs on a track and driven by a power motor, which greatly improves speed and efficiency. It is also called an electric flat car, rail transport vehicle, electric flatbed car and so on. As for the rail mounted transfer cart structure, it is generally composed of an electrical control system, traveling wheel system, power supply system, drive system, and frame. These are the basic structural components of the track flat car. The brief introduction is as follows:

1. The rail mounted transfer cart powered system: Common five powered modes are low-voltage rail, battery, sliding line, supporting cable, cable reel powered.

2. The rail mounted transfer cart drive system: mainly for braking and deceleration parts, generally adopt F series parallel shaft helical gear reducer, K series spiral bevel gear reducer, crane industry LD deceleration structure, under special circumstances, also use planet Which type of deceleration drive is used for gear reducers, etc., depending on the specific situation.

3. The rail mounted transfer cart travel wheel system: generally adopts two-axle four-wheel single-drive operation, including drive axle and the driven axle, drive axle and reducer are connected, and run from the axle including bearing housing, axle sleeve, flat key, wheels, etc.

4. The rail mounted transport trolley electrical control system: is related to the power supply mode, its operating system has two kinds: wired handle control operation and wireless remote control operation.

5. The rail mounted transfer cart frame system: the car body structure is made by welding, welded by channel steel, I-beam, angle steel and other steel.

In addition to the common structural components of these track flat cars, users may also have some special requirements, such as ladle cars (increasing the placement of ladle on the table), Electric Locomotive (with traction devices), etc.

Product advantages

Stable and reliable super heavy load bearing: The frame is welded with high-strength steel and designed with mechanical optimization. The bearing capacity can be customized to 300 tons, which can stably transport super heavy objects such as steel ladles, large castings, and heavy molds. There is no risk of deformation during long-term heavy load use; Equipped with a multi axis balancing system, it is suitable for irregular material transportation and can maintain operational stability even under harsh conditions such as high temperature and high dust.
Accurate positioning and efficient connection: relying on the track guidance system, the positioning accuracy can reach millimeter level, which can accurately dock with production line workstations, crane loading and unloading points, and storage shelves, achieving seamless material flow; Supporting PLC intelligent control and remote scheduling, it can automatically complete the transfer between two points, reduce manual intervention, and improve transfer efficiency by more than 30%.
Full scene safety protection: equipped with multiple safety devices such as electromagnetic braking, overload alarm, infrared obstacle avoidance, etc., it can automatically stop when encountering obstacles; For special scenarios, customized protection such as high-temperature insulation layers and explosion-proof motors can be installed to effectively avoid the risks of high-temperature and corrosive material transportation, ensuring the safety of both humans and materials.
Energy saving and environmental cost optimization: Mainly driven by electric power (optional low-voltage rail, battery and other power supply methods), energy consumption is reduced by 25% compared to traditional fuel equipment, and there are no exhaust emissions; Modular design of core components reduces maintenance costs by 40%, extends equipment lifespan to over 10 years, and enables controllable long-term operating costs.
Flexible customization with strong adaptability: can design straight and curved track operation plans according to site requirements, with unlimited travel distance; Supporting the installation of functions such as hydraulic lifting, tipping and self unloading, and automatic clamping, it is suitable for the material transportation needs of multiple industries such as metallurgy, machinery manufacturing, and ports, especially for high-frequency transportation scenarios with fixed routes.

Application site

Metallurgical/Steel Plant Workshop: Transporting ultra heavy materials such as steel ladles, billets, and large castings along fixed tracks, suitable for high-frequency circulation between steelmaking, continuous casting, and hot rolling processes, and resistant to high temperature and dusty conditions;
Mechanical manufacturing factory: precise docking of machine tool workstations, assembly lines, and storage areas, transportation of large molds, heavy-duty machined parts, and equipment assemblies, relying on tracks to achieve millimeter level positioning and connection;
Port/dock cargo yard: outdoor fixed route heavy-duty connection, transporting containers, steel components, heavy cargo containers, etc., suitable for long-term outdoor operation needs;
Heavy industry equipment factories (such as wind/nuclear power equipment factories): transport oversized components such as wind turbine hubs and nuclear power pressure vessels, and complete cross regional transportation in the workshop along customized tracks;
Warehousing/Logistics Park: Used for fixed path material transfer between high shelf warehouses and loading and unloading areas, connecting cranes, forklifts and other equipment to achieve efficient inbound and outbound of heavy goods;
Special industrial sites: such as chemical parks (for transporting dangerous goods containers by explosion-proof rail cars), building materials factories (for transporting cement pipe piles and heavy stone materials), with fixed route transportation requirements suitable for specific working conditions.
